Sanitary Stainless Steel Triclamp Tubular Type Ferrule Sight Glass with Protective Cover

Tubular sight glass is most common type used for observation nowadays. It offers 360 degree views, facilitating observation on working state and liquid condition inside tubes.

    Contact us
    product details

    Materials

    Body Materials: AISI-304 or AISI-316L
    Tempered glass
    Gasket Material:Silicon, EPDM, FRM
    Seat and gasket  comply with FDA 21CFR177.2600

    Standard Design

    Available in size from 1"-4", DN25-DN100 or others upon requirement
    Standards: DIN, SMS, ISO / IDF, BS / RJT, ASME / BPE.
    End connections: butt-welded, sanitary clamp, or others upon request
    Vertical or horizontal installation
    360 degree view angle

    Technical Specification

    Temperature range: 14 ~ 248℉ (-10 ~ 120℃), Silicon
    Surface treatment: CNC machining
    Tubular Sight Glass
